Output Voltage: 48VDC at 0.5A
Input Voltage: 90-260VAC at 47-63Hz
Input Current: 0.3A at 20VAC, 0.2A at 230VAC
Inrush Current:
Efficiency: 70+%
Output Ripple: % Max
Switching Frequency: 200kHz
Line Regulation: +/- 0.5%
Load Regulation: +/- %
&nbsp,Surge Protection: Common Mode
Clamping Protection: V Data, 77.5V Power
Max Surge Discharge: 200A (8/20uS) Power
Peak Pulse Current: 36A (0/000uS Data)
Shunt Capacitance:
Response Time: &lt,nS
Interface

AC Connector: IEC-320 C6
Data In/POE RJ45 Shielded Socket
80% Current Indicator: Power LED will change color

Otras características&nbsp,

Temperatura funcionamiento: -0C to +60 C
Temperatura almacenamiento: -20 to +85 C
Humedad: -0C to +60 C
Medidas: (LXWXH) 85 x 55 x 33 (mm)
Peso 3,40 gramos

Certificación

Compliance UL, EN55022 (CISPR22) class B, Meets CE
